25/50mm Outside Micrometer with ratchet stop
Please note: non-contractual pictures

25/50mm Outside Micrometer with ratchet stop

Outside Micrometers 25/50mm with ratchet stop.

More details

In stock

Heat-insulated frame, tapered (on the anvil side) for hard-to-reach places. With a standard bar except for 0-25mm A ratchet stop for a constant measuring force. Supplied in a fitted plastic case.

  • Reference:102-302
  • Brand:Mitutoyo
  • Measurement Units:Millimetre
  • Range:25-50mm / 1-2"
  • Accuracy:±2µm / ±.0001"
  • Display type:Non-digital
  • Resolution:±2µm / ±.0001"
  • Flatness:0.6µm/.000024
  • Measuring force:5-10N
  • Parallelism:2µm / .00008"
  • Data output:No
