• Range 1mm
• Accuracy ±12µm
• Graduation 0.01mm
• Repeatability 3µm
• Measuring Force 0.4-1.4N
• Graduation 50-0-50
• Flat Back
• A unique shock-proof mechanism is incorporated, providing improved immunity to shock due to sudden spindle retraction caused by high impact.
• The crystal is hard coated for durability and scratch resistance.
• Approximately 40% lighter than the conventional dial indicator.
• Provided with an improved resistance to shop floor contaminants such as water and dust.
• Due to the spindle bushing being offset from the stem, spindle movement will not be hindered or jammed when clamping along the stem.
• A pair of limit hands are provided for quick and easy tolerance judgement (GO/±NG).
